Air-Lung

Der Air-Lung war eine eigenständige Entwicklung, die wohl sehr gute Atemarbeit hatte. Wurde 1954 für die U.S. Navy entwickelt und ab 1955 allgemein angeboten.

The Air-Lung was an independent development which featured very low breathing resistance. Was develloped in 1954 for the U.S. Navy and sold publicly since 1955.

Hersteller / Manufacturer

The Garrett Corporations Air Cruisers Division, Belmar /New Jersey

Name

Air-Lung

gebaut / built

1954-1961

max. Luftlieferleistung / max.air delivery

no Information by now

Stages

1





Stage 1

Downstream

Balanced?

no

Type

membrangesteuert / Diaphragm activated

Mitteldruck / IP

no

HP-Port

no





Stage 2

no

Type

no

LP-Port

no





Gehäuse/Housing

Metal

Membrane Ø  / Diaphragm Ø

unknown

max Druck / Pressure

unknown

Anschluss/Fitting

INT

Luftauslass/ Air outtake

Kombinierte Ein-Ausatemembrane / combined diaphragm for inhale and exhale





Anschluss Gehäuse Ø/ Fitting Housing Ø

no Information by now

Mundstück/Mouthpiece

Einwegeventil Gummi / non-return rubber

Anschluss Mundstück Ø /Fitting Mouthpiece Ø

no Information by now

Gesehen wo/Seen on



Special notice

The reg featured a reserve valve

Techn. drawing

Basic Scuba by Fred S. Roberts, 2nd edition

Service manual

Basic Scuba by Fred S. Roberts, 2nd edition
