Air Master

Dieser Regler wurde in der Schweiz von APAG in Goldach gefertigt. Die Mundstücke und Membranen wurden offenbar auch von anderen Herstellern verwendet.

This reg was built in Switzerland by APAG in Goldach. The Mouthpieces and Diaphragms were used by other manufacturers too.





Hersteller / Manufacturer

Apag

Model

Air Master

gebaut / built

no Information by now

max. Luftlieferleistung / max.air delivery

no Information by now

Stages

1





Stage 1

Upstream

Balanced ?

no

Type

membrangesteuert / Diaphragm activated

Mitteldruck / IP

keiner / none

HP-Port

no





Stage 2

no

Type

no

LP-Port

no





Gehäuse/Housing

Aluminium, with colored Cover yellow or purple

Membrane Ø  / Diaphragm Ø

11,5 cm

max Druck / Pressure

200 bar ?

Anschluss/Fitting

DIN

Luftauslass/ Exhaust

Entenschnabelventil / duckbill

Anschluss Gehäuse Ø/ Fitting Housing Ø

no Information by now

Mundstück/Mouthpiece

Einwegeventil / Non-return

Anschluss Mundstück Ø /Fitting Mouthpiece Ø

no Information by now

Gesehen wo/Seen on

my Collection, Hubsi, Delphin 4/62 p1445, 4/64 p36

Special notice



Techn. drawing

no

Service manual

no

Air-Master

Air-Master

Label Airmaster

Label Airmaster

Backside Airmaster

Backside Airmaster

Inside Airmaster

Inside Airmaster

Mouthpiece Airmaster

Mouthpiece Airmaster
