Essgee Mistral

Der Mistral wurde unter Lizenz von La Spirotechnique gefertigt und verbessert (HP-Port)

The Mistal was manufactured under licence of La Spirotechnique and improved (HP-Port)

Hersteller / Manufacturer

Siebe Gorman

Name

Essgee Mistral

gebaut / built

unknown

max. Luftlieferleistung / max.air delivery

no Information by now

Stages

1





Stage 1

Upstream

Balanced?

no

Type

membrangesteuert / Diaphragm activated

Mitteldruck / IP

unknown

HP-Port

1





Stage 2

no

Type

venturi activated

LP-Port

0





Gehäuse/Housing

Metal

Membrane Ø  / Diaphragm Ø

11,5 cm

max Druck / Pressure

150 bar?

Anschluss/Fitting

INT

Luftauslass/ Air outtake

Entenschnabelventil / duckbill





Anschluss Gehäuse Ø/ Fitting Housing Ø

no Information by now

Mundstück/Mouthpiece

Einwegeventil / non-return-mouthpiece

Anschluss Mundstück Ø /Fitting Mouthpiece Ø

no Information by now

Gesehen wo/Seen on

my collection

Special notice



Techn. drawing

no

Service manual

no

Essgee-Mistral

Essgee-Mistral

Label Essgee Mistral

Label Essgee Mistral

Back-side Essgee Mistral

Back-side Essgee Mistral

Inside Essgee Mistral

Inside Essgee Mistral

Mouthpiece Essgee Mistral

Mouthpiece Essgee Mistral
