	Das war wohl der erste Regler von Heinke - sehr seltsames Aussehen und einzigartiger Luftauslass


	This was the first reg by Heinke. Looks very strange and has an unique exhaust.

Hersteller / Manufacturer	Heinke
Name	Horn
gebaut / built	no Information by now
max. Luftlieferleistung / max.air delivery	no Information by now
Stages	2

Stage 1	Upstream
Balanced?	unknown
Type	membrangesteuert / Diaphragm activated
Mitteldruck / IP	unknown
HP-Port	yes

Stage 2	upstream?
Type	no
LP-Port	no

Gehäuse/Housing	Metal
Membrane Ų / Diaphragm Ų	unknown
max Druck / Pressure	might be 150 bar
Anschluss/Fitting	INT
Luftauslass/ Air outtake	see picture

Anschluss Gehäuse Ų/ Fitting Housing Ų	no Information by now
Mundstück/Mouthpiece	T-Mundstück / T-mouthpiece
Anschluss Mundstück Ų /Fitting Mouthpiece Ų	no Information by now
Gesehen wo/Seen on	was in my collection
Special notice
Techn. drawing	no
Service manual	no

Heinke-Horn-back

Back-side-open Horn

back-side-open-II Horn

Mouthpiece Horn
