La Spirotechnique
Royal Mistral

Der Royal Mistral war der letztgebaute Zweischlauchregler von La Spirotechnique. Der Unterschied zum Mistral besteht im zusätzlichen Hochdruck-Anschluss und dem Einwegemundstück.

The Royal Mistral was the last doublehose by La Spirotechnique. It differs to the Mistral by the added HP-Port and the non-return mouthpiece.

Hersteller / Manufacturer

La Spirotechnique

Name

Royal Mistral

gebaut / built

unknown

max. Luftlieferleistung / max.air delivery

max. 600 - 700 l/min.

Stages

1





Stage 1

Upstream

Balanced?

no

Type

membrangesteuert / Diaphragm activated

Mitteldruck / IP

unknown

HP-Port

first gen. no, later 1





Stage 2

no

Type

venturi-assisted

LP-Port

no





Gehäuse/Housing

Metal

Membrane Ø  / Diaphragm Ø

11,5 cm

max Druck / Pressure

200 bar

Anschluss/Fitting

DIN

Luftauslass/ Air outtake

Entenschnabelventil / duckbill





Anschluss Gehäuse Ø/ Fitting Housing Ø

no Information by now

Mundstück/Mouthpiece

Einwegeventil Metall/ non-return metal

Anschluss Mundstück Ø /Fitting Mouthpiece Ø

no Information by now

Gesehen wo/Seen on

My collection

Special notice

hose length 450 mm, weight 1600 gr.

Techn. drawing

yes

Service manual

no

Royal-Mistral

Royal-Mistral

Label Royal Mistral

Label Royal Mistral

Back-side-HP-new Royal Mistral

Back-side-HP-new Royal Mistral

Back-side-HP-old Royal Mistral

Back-side-HP-old Royal Mistral

Back-side-no-HP Royal Mistral

Back-side-no-HP Royal Mistral

Inside-HP Royal Mistral

Inside-HP Royal Mistral

Inside-no-HP Royal Mistral

Inside-no-HP Royal Mistral

Mouthpiece Royal Mistral

Mouthpiece Royal Mistral
