PA 60 1st

Dieser Regler ist der erste deutsche Zweischlauchregler und wurde aus dem Delphin II entwickelt. Man erkennt noch das gleiche Gehäuse.
Die zweite Version des PA 60 sieht komplett anders aus.

This reg was first german doublehose reg and was develloped out of the Delphin II. See the housing. The second version of the PA 60 looks completely different..





Hersteller / Manufacturer

Dräger

Model

PA 60

gebaut / built

1955-1957?

max. Luftlieferleistung / max.air delivery

no Information by now

Stages

2





Stage 1

Upstream

Balanced ?

no

Type

membrangesteuert / Diaphragm activated

Mitteldruck / IP

keiner / none

HP-Port

no





Stage 2

upstream

Type

no

LP-Port

no





Gehäuse/Housing

Metal, chromed

Membrane Ø  / Diaphragm Ø

12 cm

max Druck / Pressure

200 bar

Anschluss/Fitting

DIN

Luftauslass/ Exhaust

runde Plastikdichtung/round Plastiksealing

Anschluss Gehäuse Ø/ Fitting Housing Ø

no Information by now

Mundstück/Mouthpiece

T-Mundstück / T-Mouthpiece

Anschluss Mundstück Ø /Fitting Mouthpiece Ø

no Information by now

Gesehen wo/Seen on

my collection, Delphin 12/62 p1640

Special notice



Techn. drawing

no

Service manual

no

PA-60 1st gen

PA-60 1st gen

Label PA 60 1st gen

Label PA 60 1st gen

Backside PA 60 1st gen

Backside PA 60 1st gen

Inside PA 60 1st gen

Inside PA 60 1st gen

Mouthpiece PA 60 1st gen

Mouthpiece PA 60 1st gen
