Mistral DW

Der Mistral DW ist der Nachfolger des Stream Air und der letztgebaute einstufige Zweischlauchautomat von U.S. Divers.

The Mistral DW is the sucessor of the Stream Air and was the last singlestage doublehose reg by U.S. Divers.

Hersteller / Manufacturer

U.S. Divers

Name

Mistral DW (1008)

gebaut / built

1958-1970

max. Luftlieferleistung / max.air delivery

no Information by now

Stages

1





Stage 1

Upstream

Balanced?

no

Type

membrangesteuert / Diaphragm activated

Mitteldruck / IP

unknown

HP-Port

no





Stage 2

no

Type

venturi-assisted

LP-Port

no





Gehäuse/Housing

Metal

Membrane Ø  / Diaphragm Ø

11,5 cm

max Druck / Pressure

unknown

Anschluss/Fitting

INT

Luftauslass/ Air outtake

Entenschnabelventil / duckbill





Anschluss Gehäuse Ø/ Fitting Housing Ø

no Information by now

Mundstück/Mouthpiece

Einwegeventil / non-return valve

Anschluss Mundstück Ø /Fitting Mouthpiece Ø

no Information by now

Gesehen wo/Seen on



Special notice



Techn. drawing

Basic Scuba by Fred M. Roberts, 2nd Edition

Service manual

Basic Scuba by Fred M. Roberts, 2nd Edition

USD Mistral

USD Mistral

Label USD Mistral

Label USD Mistral

Back-side USD Mistral

Back-side USD Mistral

Inside USD Mistral

Inside USD Mistral

Mouthpiece USD Mistral

Mouthpiece USD Mistral
