	Der Overpressure DX ist das Pendant zum Mistral von La Spirotechnique.


	The Overpressure DX is comparable to the Mistral by La Spirotechnique.

Hersteller / Manufacturer	U.S. Divers
Name	Overpressure DX
gebaut / built	1955-1957
max. Luftlieferleistung / max.air delivery	no Information by now
Stages	1

Stage 1	Upstream
Balanced?	no
Type	membrangesteuert / Diaphragm activated
Mitteldruck / IP	unknown
HP-Port	no

Stage 2	no
Type	venturi-assisted
LP-Port	no

Gehäuse/Housing	Metal
Membrane Ų / Diaphragm Ų	11,5 cm
max Druck / Pressure	unknown
Anschluss/Fitting	INT
Luftauslass/ Air outtake	Entenschnabelventil / duckbill

Anschluss Gehäuse Ų/ Fitting Housing Ų	no Information by now
Mundstück/Mouthpiece	Einwegeventil / non-return valve
Anschluss Mundstück Ų /Fitting Mouthpiece Ų	no Information by now
Gesehen wo/Seen on
Special notice
Techn. drawing	Basic Scuba by Fred M. Roberts, 2nd Edition
Service manual	Basic Scuba by Fred M. Roberts, 2nd Edition
